High Speed Heavy Duty Decoiler Quickly And Smoothly 0-20m/Min

The Decoiler Machine Can Uncoil Steel Coils Quickly And Smoothly, Reducing Manual Operations And Improving The Overall Efficiency Of The Production Line.

Description:

processes.Its body is a welded box-shaped structure,and the main power is provided by the variable frequency speed regulating motor driving the reel shaft after deceleration through the gear box.The decoiler machine supports the coil by tightening the inner hole of the steel coil,and feeds the head of the strip into the leveling machine through rotation with the cooperation of the straightening machine,thereby establishing a constant tension.

In the field of metal processing,the decoiler machine is widely used.In automobile manufacturing,the decoiler machine is used in stamping production lines to unfold steel coils to make body panels,such as doors and engine hoods;in home appliance production,the decoiler machine processes color-coated plates and galvanized plates to produce refrigerator and washing machine shells;in architectural decoration,the decoiler machine unfolds aluminum coils to make curtain walls and ceilings,supporting the precise cutting of laser cutting machines.

In terms of technical characteristics,the decoiler machine has significant advantages.It uses hydraulic or pneumatic devices to achieve radial expansion and contraction of the roll to adapt to coils with different inner diameters;it is equipped with a central control system to achieve automatic centering of the strip to prevent deviation;some models are equipped with clamping arms and wire break detection systems to ensure production safety;it uses a forced lubrication system to extend the life of the gears;key components are made of imported materials with low failure rate and long service life.

In addition,decoiler machine also derives various types according to different application scenarios,such as heavy-duty decoiler machine,hydraulic decoiler machine,double-head decoiler machine,light decoiler machine,etc.,to meet different production needs.

Specifications:

Function: Retract and release metal coils

Coil width: 0-2500mm

Coil thickness: 0-3.0mm

Load-bearing capacity: 500kg-20 tons

Standard inner diameter: φ450 ~ 530mm

Standard outer diameter: φ1200mm

Applications:

1. The body is welded with steel plates. After welding, it is annealed and polished. It has strong rigidity and good appearance. Key components are made of high-strength castings. At the same time, long-distance bearings are used to support the machine to ensure the firmness and stability of the whole machine.

2. The motor is controlled with a reducer and belt drive is used. It has good functions, high reliability and few failures.

3. The support tile adopts a four-blade design. The curvature of the tile matches the inner diameter of the material. The surface of the tile is smooth and wear-resistant, firm and durable. At the same time, it will not cause any wear to the material during use.

4. Electrical components such as AC contactors, intermediate relays, and time relays use brand components to ensure their long-term stable production.

5. The main shaft uses a reinforced type, using 45# seamless pipe, which has been tempered and will not deform under long-term load.

6. It uses a simple electrical box control, which is easy to operate the machine.

7. It has a large load capacity, simple loading, and stable operation. The material rack is automatically controlled by the induction rack, and no manual supervision is required. The degree of automation is high. At the same time, the pressing arm and hydraulic expansion can be added according to customer needs, which greatly improves the efficiency of the stamping production line and the quality of stamping products. It is an ideal unloading and unwinding equipment for the stamping production line.
